Power |
| |
Absolute voltage range (volts
DC) |
9 – 16 volts |
|
| |
Power consumption (typical)
mA |
220mA |
|
|
Physical |
| |
Overall dimensions (WxHxD)
mm |
110x115x24 |
|
| |
Product weight kg (lbs) |
0.27 (0.6) |
|
| |
Mounting method |
low profi le fl ush or
surface mount |
|
| |
Control type |
4 buttons plus multi
directional trackpad |
|
| |
Display size and type |
89 mm (3.5") sunlight
viewable QVGA (320x240
pixels) Colour Transfl
ective TFT |
|
| |
Colour palettes |
day and night modes |
|
| |
Display lighting |
White LED, sliding scale |
|
|
Connections |
| |
Connectors |
2 SeaTalkng connectors |
|
|
Approvals |
| |
CE |
conforms to 2004/108EC,
EN60945:2002 |
|
|
Environmental |
| |
Operating temperature
range |
-10°C to +70°C |
|
| |
Storage temperature
range |
-20°C to +70°C |
|
| |
Humidity |
up to 95% |
|
| |
Waterproofing standard |
CFR46 |
|
|
General |
| |
Languages |
UK English, US English,
Spanish, French, German,
Dutch, Italian,Swedish,
Danish, Norwegian.
Portuguese |
|
| |
Interfaces |
SeaTalkng, NMEA 2000,
SeaTalk, SeaTalk2 |
|
|
Display Chapters & Pages |
| |
User Instrument Page
options |
8 |
|
| |
User Page layout options |
16 |
|
| |
Depth |
depth; depth Log;
minimum depth; maximum
depth |
|
| |
Speed |
VMG to waypoint; VMG to
waypoint log; speed;
speed Log; maximum
speed; average speed;VMG
windward; log; trip;
local time and date |
|
| |
Wind |
AWS; AWA; TWS; TWA; GWD;
Beaufort; cardinal; wind
speed log; wind
direction log; AWS
maximum;AWA maximum; TWA
maximum; TWA minimum;
TWS maximum; TWS minimum |
|
| |
Compass |
heading; heading log;
locked heading: tack
heading; average heading |
|
| |
Navigation |
BTW, XTE, ETA; TTG, CMG;
DMG; DMG and CMG, DTW |
|
| |
GPS |
COG, SOG, COG Graph, SOG
Graph, COG and SOG; Lat
and Long; satellites;
satellites and HDOP |
|
| |
Engine |
engine RPM; fuel fl ow;
fuel level; engine hours:
fuel economy; average
fuel rate, coolant
temperature, oil
pressure; oil
temperature; boost
pressure; battery
temperature; coolant
pressure; trim position |
|
| |
Battery |
battery voltage; battery
amps, battery
temperature, unit
voltage graph |
|
| |
Environment |
sea temperature;
barometric pressure;
barometric pressure log;
sunset & sunrise;
maximum sea temperature:
minimum sea temperature;
sea temperature graph,
set and drift; air
temperature; air
temperature log; maximum
air temperature; minimum
air temperature |
Requires Airmar weather
transducer. |
| |
Alarms |
depth, wind, speed,
temperature, off course,
battery volts, last fix,
waypoint arrival, MOB |
